Stomp Z3-140 (14/12”) Small Wheel Pit Bike

STOMP Z3-140 STOMP RACING PIT BIKE

The Z3-140 still boasts the ‘exclusive to Stomp’ SR140C Z40 cam engine. Stomp buy in the YX140 and then fettle the engine with stiffened valve springs & a high lift race cam (known as the Z40 cam). The result is 2hp more than any other YX140 engine on the market. It might not be quite Zhongshen 155 territory but its most of the way there and significantly cheaper to install than the ZS155. If you look after the SR140C, it will prove a very reliable and cheap engine to run. The new look Z3-140 also comes with updated pro foot pegs and polished hubs to complete the new look

• Stomp Racing SR140C Z40 race cam
• Start-in-gear, all-up 4 speed gearbox
• 14hp at rear wheel
• 26mm race carb with double foam filter
• Aluminium shot blast finished cases with Stomp logo
• CNC oil cooler with braided steel hoses
• SDG2 heavy duty cradle frame for ultimate stiffness and control
• Removable rear subframe & bolt on engine hangers
• Revised light-weight tig welded 430mm swing arm
• Entended 735mm cnc machined usd oil filled forks
• Drop forged black anodised triple clamps (yokes)
• Nitrogen filled 290mm piggy back shock with steel bushes
• 14/12 sdg wheels with steel rims for strength
• Superb durable and tough innova pattern mx tyres
• Improved and revised light-weight brake master cylinders and calipers
• Vented light-weight rotors
• Alloy oval exhaust muffler
• Mandrill bent big bore 32mm OD race pipe
• Features full length alloy heat shield for style and protection
• Pro-taper style minibike bars
• Renthal style soft rubber grips
• Forged alloy clutch & brake levers
• 420 KMC chain with engraved alloy/nylon chain guide
• 420 41t lightweight durable rear sprocket
• 420 16t front sprocket
• Fold back gear selector
• NEW upgraded PRO footpegs
• NEW reinforced poly resin 5.5 ltr fuel tank with alloy cnc filler cap
• NEW revised firmer seat with Stomp logo
• NEW Detroit hi impact polypropylene plastics
• Wrap around crf number board with front brake pipe tidy
• New Stomp race graphics kit with Stomp race sponsor’s logos
• Seat height 82cm
• Dry weight 71kg
• Weight limit 15 stone

Terms and conditions of supply for all Dirt bikes and Quad Bikes.

All motorbike’s and quad-bikes can be dangerous if used incorrectly. Please wear appropriate safety equipment at all times when using bikes or similar machines. The use of any powered vehicle could involve the risk of injury or death. Please use these products in a responsible manner. All bikes and quads should be throroughly checked that they are safe to use before every ride. CMW bikes is not responsible for any injury or accident whilst using or working on these machines.

The products that we supply are technical & mechanical products, which require mechanical knowledge and ability to use and maintain. A small amount of assembly is required of assembly is not requested. Items such as fitting the foot rests, wheels and handle bars, (this may vary depending on product purchased) the bike should also be checked before first use and then regularly to ensure all the essential bolts and fittings are secure and correctly adjusted. You should not purchase these products unless you have a good understanding of how to use and maintain mechanical products.

None of the bikes we provide are ‘road legal’ and are not for use on the public highway. These bikes are intended to be enjoyed on private property. Use of these bikes on a public highway could result in criminal proceedings.

The Following parts are not covered by the  warranty on this item.
Chains & Belts;
Fairings/ bodywork (unless damaged during delivery. Photos required within 24 hours of receipt)
Pull Starts or Inner Cogs;
Clutches or springs
Brake Cables, Disks and Callipers;
Exhaust Pipes;
Tyres, Wheels, valves and Inner Tubes;
Spark Plugs;
Any other parts of a similar wear and tear nature to those listed above and any part that has been damaged as a result of an accident, misuse or lack of maintenance.

Terms of Warranty

Due to its size and weight this item is covered by a replacement parts warranty, if your machine develops a fault within the warranty period of 30 days, you need to contact us and we will advise how to best rectify the problem and dispatch replacement parts, without charge providing the faulty parts are covered by the warranty.
Please note customers will be expected to fit the parts themselves, guidance will be available on technical issues. We will require videos and a description of the issue to be able to resolve these issues quickly.

Important Shipping/Collection Information

We offer multiple options for shipping which are displayed at checkout. We always do our best to get your order to you as quickly as possible but on some occasions there may be a slight delay. If you have selected the option to have your order fully assembled this may add 1-2 business days to your order at our busier periods. Local delivery/Collection can be selected at check out, although we carry a lot of stock locally some of our stock is stored at our distribution centre which would need to be sent to our store for local delivery/collection to be possible. Please call us on 07745557756 before placing your order to check if we have the product in local stock if you are looking for the item urgently.
